Page 85= Key 1 = Key 2 = Key 3 = Maximum or consumption = Minimum or supply
Table 9
In and outputs
A remote Bit is assigned to each in- or output, that can be controlled externally. If this remote Bit=0, the in- or output
is controlled by the UMG 503 only. If the remote Bit=1, the in- or output is controlled externally.
Description Address Format r/w
1)
Comment
Inputs 0048 word[3]
r/w Bit 0 Change over summer time (Winter=0, Summer=1)
r/w Bit 1 Remote, change over summer time
r/w Bit 2 Relay output 2
r/w Bit 3 Remote Bit, Relay output 2
r/w Bit 4 Relay output 1
r/w Bit 5 Remote Bit, Relay output 1
Bit 6..15 Free
r/w Bit 0 Remote Bit, Tariffs
r Bit 1 Synchronize of the internal clock
Bit 2..3 Free
r/w Bit 4 Reset of real power EMAX
r/w Bit 5 Remote Bit, Reset of real power EMAX
Bit 6..15 Free
r Bit 0..1 Tariff real energy consumption
r Bit 2..3 Tariff reactive energy Ind.
r Bit 4..5 Tariff reactive energy cap.
Bit 6..15 Free
Outputs 0032 word[3]
r Bit 0 Measuring range of voltage in L1 exceeded
r Bit 1 Measuring range of voltage in L2 exceeded
r Bit 2 Measuring range of voltage in L3 exceeded
r Bit 3 Measuring range of voltage in L1 underscored
r Bit 4 Measuring range of voltage in L2 underscored
r Bit 5 Measuring range of voltage in L3 underscored
Bit 6..15 Free
r Bit 0 Measuring range of current in L1 exceeded
r Bit 1 Measuring range of current in L2 exceeded
r Bit 2 Measuring range of current in L3 exceeded
r Bit 3 Measuring range of current in L1 underscored
r Bit 4 Measuring range of current in L2 underscored
r Bit 5 Measuring range of current in L3 underscored
Bit 6..15 Free
r Bit 0..2 Watchdogcounter
r Bit 3 Auxiliary input
Bit 4..15 Free
1)
r/w = read/write
