janitza UMG 503 - Table 6 c & 6 d: Max;Min Values (Integer); Maximum Values in Integer Format; Minimum Values in Integer Format

Page 82 = Key 1 = Key 2 = Key 3= Maximum or consumption = Minimum or supply.
Table 6c
Maximum values in integer format
Maximum values Index Address(dez) r/w
1)
Format Unit Comment
Current 8314 r word[3] A L1, L2, L3
Voltage 8317 r word[3] V N-L1, N-L2, N-L3
Voltage 8320 r word[3] V L1-L2, L2-L3, L1-L3
Real power
2)
8323 r word[3] W L1, L2, L3
Apparent power 8326 r word[3] VA L1, L2, L3
Reactive power
3)
8329 r word[3] var L1, L2, L3
cos(phi)
3)
8332 r word[3] L1, L2, L3
Frequency 8335 r word[3] Hz L1, L2, L3
Real power, sum
2)
8338 r word W
Apparent power, sum 8339 r word VA
Reactive power, sum
3)
8340 r word var
cos(phi), sum
3)
8341 r word
Current, N 8342 r word A Current in neutral conductor
Partial harmonics _U 8344 r word[20][3] V Partial harm. 1-20; L1, L2, L3
Partial harmonics _I 8404 r word[20][3] A Partial harm. 1-20; L1, L2, L3
Total harmonic distortion _U 8464 r word[3]
0
/00 L1, L2, L3
Total harmonic distortion _I 8467 r word[3]
0
/00 L1, L2, L3
Real power EMAX, sum
2)
8470 r word W
Current mean value 8663 r word[3] A L1, L2, L3
Table 6d
Minimum values in integer format
Minimum values Index Address(dez) r/w
1)
Format Unit Comment
Current 8471 r word[3] A L1, L2, L3
Voltage 8474 r word[3] V N-L1, N-L2, N-L3
Voltage 8477 r word[3] V L1-L2, L2-L3, L1-L3
Real power
2)
8480 r word[3] W L1, L2, L3
Apparent power 8483 r word[3] VA L1, L2, L3
Reactive power
3)
8486 r word[3] var L1, L2, L3
cos(phi)
3)
8489 r word[3] L1, L2, L3
Frequency 8492 r word[3] Hz L1, L2, L3
Real power, sum
2)
8495 r word W
Apparent power, sum 8496 r word VA
Reactive power, sum
3)
8497 r word var
cos(phi), sum
3)
8498 r word
Current, N 8499 r word A Current in neutral conductor
Partial harmonics _U 8501 r word[20][3] V Partial harm. 1-20; L1, L2, L3
Partial harmonics _I 8561 r word[20][3] A Partial harm. 1-20; L1, L2, L3
Total harmonic distortion _U 8621 r word[3]
0
/00 L1, L2, L3
Total harmonic distortion _I 8624 r word[3]
0
/00 L1, L2, L3
Real power EMAX, sum
2)
8627 r word W
1)
r/w = read/write
2)
Sign - = Supply, + = Consumption
3)
Sign - = cap, + = ind
