janitza UMG 503 - Table 7: Energy (Integer); Energy Values in Integer Format

Page 83= Key 1 = Key 2 = Key 3 = Maximum or consumption = Minimum or supply
Table 7
Energy in integer format
Energy Index Address(dez) r/w
1)
Format Unit Comment
Real energy, consumption 9000 r long Wh Scale see address 9102
Real energy, supply 9001 r long Wh Scale see address 9102
Real energy without rev. running stop 9002 r long Wh Scale see address 9102
Reactive energy, capacitive 9003 r long varh Scale see address 9102
Reactive energy, inductive 9004 r long varh Scale see address 9102
React. energy without rev. running stop 9005 r long varh Scale see address 9102
1)
r/w = read/write
