Page 80 = Key 1 = Key 2 = Key 3= Maximum or consumption = Minimum or supply.
Table 4
Averaging times of the mean values.
The averaging times cannot be retrieved via Profibus DP V1.
Description Index Address(dez) Type Comment
DPV1 DPV0/MODB.
Current 4000 char[3] L1, L2, L3
Voltage N-L 4003 char[3] L1, L2, L3
Voltage L-L 4006 char[3] L1-L2, L2-L3, L1-L3
Real power 4009 char[3] L1, L2, L3
Apparent power 4012 char[3] L1, L2, L3
Reactive power 4015 char[3] L1, L2, L3
cos(phi) 4018 char[3] L1, L2, L3
Frequency 4021 char[3] L1, L2, L3
Real power, sum 4024 char
Real power EMAX 4156 char 5=5, 6=10, 7=15, 8=30, 9=60Minutes
Apparent power, sum 4025 char
Reactive power, sum 4026 char
cos(phi), sum 4027 char
Current, N 4028 char
Total harmonic distortion _U 4150 char[3] L1, L2, L3
Total harmonic distortion _I 4153 char[3] L1, L2, L3
Partial harmonics _U 4030 char[20][3] Partial harmonics 1-20; L1, L2, L3
Partial harmonics _I 4090 char[20][3] Partial harmonics 1-20; L1, L2, L3
1)
r/w = read/write
Table 5
Internal control word
Description Address(dez) r/w
1)
Format Comment
Internal control word 5000 r/w char[17] Byte 0 Only internal use.
Byte 1 Only internal use.
Byte 2 Delete minimum value. (Byte > 0)
Byte 3 Delete maximum value. (Byte > 0)
Byte 4 Only internal use.
Byte 5 Only internal use.
Byte 6 Delete real energy. (Byte > 0)
Byte 7 Delete reactive energy. (Byte > 0)
Byte 8 Only internal use.
Byte 9 Only internal use.
Byte 10 Only internal use.
Byte 11 Only internal use.
Byte 12 Only internal use.
Byte 13 Only internal use.
Byte 14 Only internal use.
Byte 15 Only internal use.
Byte 16 Only internal use.
To change a byte of the "internal control word", the "internal control word" must be read, and the changed word must
be written back to address 5000.
Attention!
If the bytes with the comment "Only internal use" are changed, this may lead to a faulty operation of
UMG 503!
Format of time information: {char: Year, month, day, hour, minute, second} Year: 00 .. 99 = 2000 .. 2099
