P/N 960-100940R_Rev. A © 2016, JCM American Corporation
1-1
GEN5™ Series
Printer
Section 1
Section 1 provides a general overview of the
GEN5™ Series Printer, shown in Figure 1-1. This
section is designed to help the user navigate
through this guide with ease. It includes the follow-
ing information:
GEN5 Printer Unit
Model Descriptions
Precautions
Primary Features
Component Names
Specifications
Unit Dimensions
Technical Contact Information
In order to make operating this device and navigat-
ing within this manual easier, the following illus-
trations are used:
Safety Instructions need to be observed in order to
protect the operators and the equipment; these are
identified with Bold text and the following
pictographs:
Special Notes affect the use of the Printer; these are
identified with italic text and the following
pictograph:
Steps require the operator to perform specific
actions; these are identified with sequential
numbers (1, 2, 3, etc.).
1 GENERAL INFORMATION
GEN5 Printer Unit
Figure 1-1 GEN5 Printer Unit
