P/N 960-100940R_Rev. A © 2016, JCM American Corporation
Section 7 GEN5™ Series Printer Exploded Views & Parts Lists
GEN5 Bottom Tray Assembly Parts List
Table 7-6 GEN5 Bottom Tray Assembly Parts List
Ref No. Part No. Description Qty Remark
1 370-00016-100 Bracket, Main 1
2 350-00054-100 Grounding Foil 1
3 310-0
0112-100 Bracket Release Bar 1
4 310-0
0116-100 Rail 2
5 4
85-00027-100 Lock Spring 1
6 4
85-00030-100 ‘W’ Spring 1
MET
Spacer, W-
Shape, SS 17-7
7 485-00090-100 Grounding Spring 4
8 4
73-00080-100 Screw, PLASTITE FLPHP 6x0.313 10
9 4
73-00073-100 Screw, MACH BTH M3x 5x8mm 3
10
310-00115-100 Guide, Release Bar 1
11
370-00040-100 HLDR Conn 1
12
473-00019-103 SCR, MACH PNHPH, M3x4mm Screw Lock Spring 2
13
473-00072-100 SCR, SHLDR 4-40 1/8 x 3/16 2
14
473-00497-100 SCR, MACH PN# 9PH #2 x 3/16 2
15
485-00019-100 SPR - EXT 1
16
150-00028-100 CABLE, ASSY. BEZEL 1
17
486-00001-100 WIRE SADDLE NYLON 1
To Next Page
