Section 7 GEN5™ Series Printer Exploded Views & Parts Lists

GEN5 Top Presenter Parts List

Table 7-4 GEN5 Top Presenter Parts List

Ref No. Part No. Description Qty Remark

1 370-00019-100 Top Presenter 1

2 370-00021-100 Floating Part 2

3 3

70-00026-100 Floating Part, Cover 1 Plate - Spring

4 4

85-00175-100 Spring, Compression 2

5 4

60-00006-100 Roller, Pinch 1

6 4

73-00078-100 Screw, PLASTITE, PNHPH #4x0.25 2
