P/N 960-100940R_Rev. A © 2016, JCM American Corporation
Section 1 GEN5™ Series Printer General Information
Specifications
Technical Specifications
Table 1-4 GEN5 Technical Specifications
Print Speed:
90mm/second
(3.5”/second)
Print & Present: 2.2 seconds
Memory: 4MB with 8MB RAM
Template Storage:
4MB
*
*. Template Storage and Graphic Storage use shared memory.
Graphic Storage:
4MB
*
Resolution: 8 dots/mm (203 dpi)
Print Width: 62mm (true near edge printing)
Page Mode:
Full page mode printing (simultaneous 4 orientation printing; 0 degrees,
90
degrees, 180 degrees, 270 degrees; Line and Box Draw; Bitmap
Graphics; Printer residence (stored in Flash Graphics)
Media: Direct Thermal, Top Coated, Fanfold and Perforated
Paper Specifications: 65mm (W) x 156mm (L) 4.5 mil, 1 Color/2 Color
Duty Cycle: Max Continuous Feed of 1200 Tickets w/ 18 second delay between prints
Media Capacity: 300 STD (600/900/1200 Options)
Bezel Control: Two High Current Ticket Printing Bezel Control
Port
s
Update Port: USB Download Port
Printer Language: TCL Printer Language (Page Descriptio
n
Language), subset of ESCP2
Fonts: 8 (2.5, 3.3, 4.0, 5.5, 5.6, 7.3, 10.1, 20.5 cpi)
Font Scalability Independently Scaled form 1x - 7
x
in both Height and Width
Bar Codes:
PDF-417, Interleaved 2 of 5, Code 39, UPC-A, UPC-E, UPC-E-2,
UPC-E-5, Codabar, EAN-13, EAN-8, Code 128, MSI, Data Matrix
Communications:
USB 2.0 (Full Speed at 12Mbps);
USB Download Port;
Compliant with GSA GDS, IGT USB/Netplex,
RS-232C
