P/N 960-100940R_Rev. A © 2016, JCM American Corporation
Section 2 GEN5™ Series Printer Installation
Manual Baud Rate Setting
If it becomes necessary to manually configure
Baud Rate Settings on the GEN5 Printer Unit, per-
form the following steps:
1. Remove the rubber plug from the side of the
Printer (refer to Figure 1-4 j).
2.
Set DIP Switches SW1 through SW4 to select the
desired Baud Rate (Tab
le 2-1).
3. Open the Printer lid.
4. Press and hold the Feed Button for one (1)
second.
5. Close the Printer lid.
6. Power cycle the Printer Unit.
7. Print a Configuration Ticket to verify that the
Baud Rate Setti
ng has been changed
.
Disabling the Paper Low Sensor
If it becomes necessary to disable the GEN5
Printer Unit’s Paper Low Sensor, perform the fol-
lowing steps:
1. Remove Paper from the Print Head.
2. Put the GEN5 Printer in a "Paper in
Chute" con-
dition. Cover the Taken Sensor (Figure 2-11 e)
with your finger or a Ticket.
3. Press and hold the Feed button (Figure 2-4 a) for
3 second
s. If the GREEN Ready light flashes, the
Paper Low Sensor has just been turned
ON. If the
RED Fault light flashes, the Paper Low Sensor
has just been turned OFF.
