JCM GEN5 Series User Manual

P/N 960-100940R_Rev. A © 2016, JCM American Corporation
1-8
Section 1 GEN5™ Series Printer General Information
Ticket Specifications
Figure 1-5 illustrates the GEN5 Printer Unit’s Ticket Specifications.
Table 1-8 GEN5 Ticket Specifications
Dimensions:
65mm x 156mm + -1mm
Paper Type: Direct Thermal, Top Coated, Fan Fold, Perforated
Paper Thickness: 4.5 mil
Color: 1 Color/ 2 Color
NOTE: All dimensions in millimeters
65 ± 1
MAX AREA FOR
PRE-PRINTED GRAPHIC IMAGES
STAY OUT AREA
152.9 MAX
WHITE GAP
31.74
1.51 MAX
5.08
156 ± 1
10.16
43.1 MAX
Figure 1-5 GEN5 Printer Unit Ticket Specifications
