P/N 960-100940R_Rev. A © 2016, JCM American Corporation
GEN5™ Series
Printer
Appendix B
B GLOSSARY
B
1 Bezel
a removable Plastic Assembly attached to the front of the Printer Unit. It features a rect-
angular access slot for easy retrieval of Tickets. Bezels are available in different shapes,
colors and sizes to accommodate different mounting options ... 1-2
D
2DIP Switch
an acronym for Dual Inline Package Switch, a mountable two-position slide switch con-
taining up to 16 individual switches per block assembly located on a Printed Circuit
Board (PCB), which may be set to an ON or OFF position. DIP Switches are often used
in circuits where manual selection of operational changes, options and features is de-
sired ... 2-1
F
3 Firmware Updating
a process whereby the System Firmware stored in memory is updated periodically for
improved performance. ... 6-1
P
4 Pictograph
small internationally recognized safety and attention symbols placed to the left of
Notes, Cautions and Warnings throughout a JCM Maintenance Manual ... 1-1
5 Precautions
Special instructions and warnings that appear in JCM Maintenance Manuals. Precau-
tions are intended to promote personal safety and prevent damage to equipment when
working with the applicable JCM Product ... 1-2
T
6 Ticket Jam
on occasion, wrinkled or damaged Tickets become stuck within the mechanical area of
the Printer Unit. This condition may occur due to a damaged or degraded Ticket, or due
to a Paper feed error. ... 2-7
7TTL
an acronym for Transistor to Transistor Logic levels ... 2-4
