P/N 960-100940R_Rev. A © 2016, JCM American Corporation
Section 7 GEN5™ Series Printer Exploded Views & Parts Lists
GEN5 Lid Upper Presenter Parts List
Table 7-5 GEN5 Lid Upper Presenter Parts List
Ref No. Part No. Description Qty Remark
1 370-00020-102 GEN5 Lid 1
2 100-00017-100 Top Presenter Assy. 1
3 4
00-00007-100 Print Mechanism 1
4 3
70-00023-100 Base Locker, Latch 1
5 3
70-00022-100 Locker, Latch 1
6 310-0
0117-100 Cutter, Top Presenter 1
7 3
70-00024-100 Hinge 1
8 3
70-00025-100 Hinge, Pin 1
9 4
85-00013-100 Spring, Torsion Hinge 1
10
473-00083-100 Screw, Cutter MACH FLHPH, 6-32x1/4 2
11
473-00049-100 Screw, Print Mech, MACH PNHPH, M3x5mm 4
12
486-00033-100 Retaining Ring, Hinge Pin, E-RING 0.25in. dia. 1
13
473-00082-100 Screw, Top Presenter, PLASTITE-FLHPH #6x.375 4
14
482-00012-100 Washer, Lock 2
15
485-00008-100 Spring, Compression 1
16
473-00078-100 Screw, PLASTITE-PNHPH #4x.025 2
17
150-00023-100 Print Head Harness 1
To Next Page
