JCM GEN5 Series User Manual

P/N 960-100940R_Rev. A © 2016, JCM American Corporation
4-1
GEN5™ Series
Printer
Section 4
This section provides disassembly and reassembly
instructions for the GEN5 Printer, and includes the
following information:
• Tool Requirements
• Paper Tray Removal
• CPU Board Removal
• Upper Presenter Removal
• Print Mechanism Disassembly
• Bottom Presenter Mechanism Disassembly
Tool Requirements
The following tools will be required to perform
Printer disassembly and reassembly.
• #1 & #2 Phillips Screw Drivers
• Flat-blade Screw Driver
• Needle-nose Pliers
•
1
⁄
4
” Nut Driver
Paper Tray Removal
To remove the Paper Tray, proceed as follows:
1. Remove four (4) mounting screws from the Paper
Tray (Figure 4-1 a
1
, a
2
, a
3
& a
4
).
2. Lift the Paper Tray up slightly, then disconnect
the LED panel con
nection (not shown).
3. Lift the Paper Tray up and off the Bottom Tray.
CPU Board Removal
To remove the CPU Board from the GEN5 Printer
unit, proceed as follows:
1. Disconnect six (6) Harness connections (Figure
4-2 a
1
thru a
6
.
2. Remove the Ground Screw (Figure 4-2 b
1
).
3. Remove three (3) screws (Figure 4-2 b
2
thru b
4
).
4. Lift the CPU Board off the base.
5. Disconnect the Print Head connec
tion (Figu
re 4-2
a
7
).
Upper Presenter Removal
To remove the Upper Presenter from the GEN5
Printer unit, proceed as follows:
1. Remove two (2) screws (Figure 4-3 a
1
and a
2
)
from the bottom side of the Bottom Tray.
2. Lift the Upper Presenter (Figure 4-3 b) out of the
Bot
tom Tray.
4 DISASSEMBLY/REASSEMBLY
WARNING: Before performing this
procedure, observe the ESD WARNING
in “User Cautions” on page 1-2.
Figure 4-1 Remove Paper Tray Mounting Screws
a
1
a
2
a
3
a
4
Figure 4-2 CPU Board Removal
a
1
a
2
a
3
a
4
a
5
a
6
a
7
b
1
b
2
b
3
b
4
