JCM GEN5 Series User Manual

P/N 960-100940R_Rev. A © 2016, JCM American Corporation
6-4
Section 6 GEN5™ Series Printer Firmware Updating and Testing
5. Click “Select FIRMWARE” to open the Browser
(Figure 6-11 b).
6. Click the “
Full Upgrade” Screen Button (Figure
6-12 a) to begin the Firmware download.
7.
Look for the “***Printer Successfully
updated
***” message display (Figure 6-13
a). When it appears, the Firmware Upgrade is
co
mplete.
8. From the Printer, press the “FEED” button twice
within 2 seconds to print a Configuration Ticket.
Verify that the updated Firmware loaded properly
(refer to Figure 6-2 and Table 6-1).
This completes the Firmware Download procedure.
JCM Printer Driver Installation
Perform the following steps to download and install
the
JCM Printer Basic Driver. (Refer to Figure 6-1
for the necessary Tools and Harness Connections).
1. Download the “JCM_Printer_Driver”.zip file from
www.jcmglobal.com to a new folder in the PC’s
Downloads directory (Figure 6-5 a).
2. Open the PC’s Downloads directory where the
“
JCM_Printer_Driver”.zip file is located, then
extract the files into a new folder on the PC Desk-
top (e.g., click
Make New Folder, then enter a new
folder name, such as JCM_Printer_Driver).
3. From the
JCM Printer Basic Driver - Installation
folder, double-click the “
setup.exe” file to install
the application.
Running the JCM Printer Basic Driver
To run the JCM Printer Basic Driver Application:
1. Click the Start button on the PC desktop.
2. Click
Programs, then scroll down to JCM.
3. Click on the “JCM Printer Basic Driver” icon.
The JCM Printer Basic Driver user interface will
appear (Figure 6-14).
NOTE: Look for a GEN5 Firmware
filename that begins with “5”.
NOTE: When upgrading to a different
Firmware version, deselect the Erase
User Settings checkbox (refer to Figure
6-11 c). Downloading time runs longer if
the checkbox is selected.
Figure 6-11 Verify Connection & Select Firmware
a
b
c
NOTE: Download progress is indicated
by a blue Progress Bar and a green
Flashing Square that appears on the
upper right side of the display screen.
Figure 6-12 Start Full Firmware Upgrade
a
Figure 6-13 Firmware Upgrade Completed
a
NOTE: Microsoft .NET Framework 4.5 is
required to run the JCM Printer Basic
Driver. If necessary, this component can
be installed from the JCM Printer Basic
Driver folder.
