JCM GEN5 Series User Manual

P/N 960-100940R_Rev. A © 2016, JCM American Corporation
1-5
General Information GEN5™ Series Printer Section 1
Component Names
Figure 1-4 illustrates the GEN5 Printer component names and locations.
Figure 1-4 GEN5 Printer Components
a) RS232/USB Coil Interface Cable
b) Coil Interface Cable Connector
c) Lid Latch
d) Copper Shield
e) Bezel LED Connector
f) Bottom Tray
g) Upper Lid
h) Feed Button
i) Status LEDs
j) DIP Switch (under Rubber Boot)
k) USB Update Port
l) Paper Tray (300 note)
d
c
b
a
e
f
g
h
i
j
k
l
