JCM GEN5 Series User Manual

P/N 960-100940R_Rev. A © 2016, JCM American Corporation
7-4
Section 7 GEN5™ Series Printer Exploded Views & Parts Lists
GEN5 Bottom Presenter Parts List
Table 7-2 GEN5 Bottom Presenter Parts List
Ref No. Part No. Description Qty Remark
1 370-00170-100 Presenter Bottom 1
2 340-00002-101 Motor, Presenter 1
3 3
10-00199-100 Mounting Bracket, Presenter Motor 1
4 1
40-00099-100 Taken Sensor 1
5 2
40-00000-100 Gear, SPUR 48 TOOTH 2
6 3
70-00026-100 Floating Part, Cover 1
7 3
70-00021-100 Floating Part 2
8 4
60-00104-100 Roller, Platen 2
9 4
60-00006-100 Roller, Pinch 1
10
485-00175-100 Spring, Compression 2
11
486-00032-100 Bearing, Plastic 4
12
473-00050-100 Screw, MACH, PNHPH 4-40x0.187 2
13
482-00012-100 Washer, Lock Motor 5
14
486-00044-100 Retaining Ring, 0.188 4
15
473-00078-100 Screw, PLASTITE PNHPH #4x0.25 6
16
150-00033-100 Ground Harness 1
17
150-00027-100 Cable, Assy-Taken Sensor 1
18
482-00028-100 Washer #6 2
19
473-00079-100 Screw, PLASTITE 48-2, #6x0.25 2
