P/N 960-100940R_Rev. A © 2016, JCM American Corporation
7-2
Section 7 GEN5™ Series Printer Exploded Views & Parts Lists
GEN5 Entire Unit Parts List
Table 7-1 GEN5 Entire Unit Parts List
Ref No. Part No. Description Qty Remark
1 100-00016-101 Sub-Assy., LID Upper Presenter 1
2 100-00019-100 Sub-Assy., Bottom Tray 1
3 1
00-00020-101 Sub-Assy., Paper Tray 1
4 1
00-00164-100 Sub-Assy., Bottom Presenter 1
5 1
40-00243-102 PCBA Assy., GEN5 1
6 3
70-00015-100 Base 1
7 1
50-00373-100 Cable Assy., Coil 14 RS232/USB 1
8 3
62-00253-100 Label, Tray JCM Arrow 1
9 3
62-00256-100 Label, Lid, JCM Type 5 1
10
362-00080-101 Label, No Tamper 1
11
473-00082-100 SCR,FLHPH,PLASTITE 48-2,#6x3/8 10
12
473-00117-100 STUD, SELF CLINCHING PEM FHS-632-8 OR EQ. 1
13
476-00008-100 NUT, HX, #6-32, Narrow. 1
14
473-00079-100 SCR,PNHPS,PLASTITE 48-2,#6x1/4 4
15
473-00081-100 SCR,PNHPH,PLASTITE 48-2,#6x3/8 1
16
486-00031-100 CLAMP, CBL, N4-BLK 1
17
150-00033-100
GROUND HARNESS FROM BOTTOM PRESE
NTER
ASSY
1
