COMPLEX RADIO CONTROL SYSTEM
The supply voltage can be connected to the receiver in the
following ways:
or a stabilized BEC voltage source (either as a separate device or
integrated in the speed controller).
ź Via throttle channel (when using the speed controller BEC).
ź Using the Battery ports or any free or open receiver port.
Note: never connect two different voltage sources in parallel, even
if they seem to have the same parameters.
źVia the MPX connector included on EPC receivers (Extended Power
Connector).
REX A receivers be powered by low-resistance Li-XXX type batteries
For multirotors, use either a BEC output from a single controller
or, in case of Opto-type controllers, use an external stabilised
source. Never connect voltages from several BEC circuits in
parallel.
3.2. Power supply
When designing a wiring system in the model, always be careful
about choosing a suitable power supply so that it is sufficiently
current-rated and its output voltage is compatible with the
receiver, servos and other electronics. It is recommended that the
EN
