COMPLEX RADIO CONTROL SYSTEM
The internal barometer is being calibrated at the same time as the
gyroscope to create a reference zero level for calculating the
relative altitude.
stabilisation is armed and ready for flight.
1 . I n t h e r e ce i v e r m e n u , v i e w
„Tel e m e t r y/Sensor Calibration”
s c r e e n . A c t i v a t e t h e " S t a r t
calibration" command and follow
the instructions.
4. After completing the calibration, please make sure that the total
GForce displayed on the Telemetry screen lies in the range of
0.99 - 1.01G (measured at rest).
2. The receiver must be placed on a
horizontal board on one of its six
sides and kept still for about 2
seconds. Once the position is
correctly recorded, the "Remaining
positions" line reduces one point at a
time, rotate the receiver through all six surfaces.
Calibration of the accelerometer is a more complex process. The
receiver is already calibrated from the factory, but due to the Earth's
gravitational field, which is not constant all over the planet, the
accelerometer can show inaccurate measurements. We recom-
mend you to calibrate the accelerometer also when you configure
the receiver in a new model for the first time:
3. After calibrating the last position, the receiver will report
successful completion.
EN
37
