MAINTENANCE
TURN OFF all POWER supply switches.
Tool
Phillips Screwdriver,
Long Nose Pliers, Pliers
: Board Holder
: Securing Screw for Part
1. Noise Filter (NF1, NF2)
Board Holder (12 places)
2. Inverter PCB (INV1, INV2)
Securing Screw for Part (M3) (four places)
Securing Screw for Part (M5) (four places)
3. Reactor (DCL)
Securing Screw for Part (M4) (four places)
4. Terminal Block (TB1)
Securing Screw for Part (M4) (two places)
4. Terminal Block (TB3)
Securing Screw for Part (M4) (two places)
5. Main Power PCB (MPB1, MPB2)
Board Holder (12 places)
Refer to previous page for item No.1 to 5.
To Next Page
