(Main Parts)
MAINTENANCE
4-72
SM-18006
● Arrangement of Inverter Power Unit
(H,Y)VWH(P,R)144B32S, (H,Y)VWH(P,R)168B32S,
(H,Y)VWH(P,R)192B32S and (H,Y)VWH(P,R)216B32S Only
Radiation Plate 1
Inverter PCB (INV1) Inverter PCB (INV2)
Radiation Plate 2
Main Power PCB (MPB1)
Main Power PCB (MPB2)
