IFC-3030 Programming Manual — P/N 52025:C 08/05/2005 99
Abort Switches Releasing Applications
NOTE: Panel circuit modules are not suitable for the release of agents.
Type Codes designed for releasing zone inputs (SLC monitor modules).
Type Codes designed for releasing zone outputs (SLC control modules).
Table 5:
Type Code What the Type Code does Refer to
ABORT SWITCH
(tracking)
Provides an abort function through
a monitor module (connected to a
UL-listed abort station) for a
releasing zone.
“How to Program an Abort Switch”
on page 100
MAN. RELEASE
(latching)
Provides a manual release through
a monitor module (connected to a
UL-listed pull station) for a releasing
zone.
“How to Program a Manual
Release Switch” on page 101
MAN REL DELAY
(latching)
Provides a manual release with a
10-second delay through a monitor
module (connected to a UL-listed
pull station) for a releasing zone.
“How to Program a Manual
Release Delay Switch” on
page 102
SECOND SHOT
(latching)
Provides a second manual release
through a monitor module
(connected to a UL-listed pull
station) for a releasing zone.
“How to Program a Second Shot
Switch” on page 104
Table 6:
Type Code What the Type Code does Refer to
REL END BELL Activates an NAC audio or visual
device when releasing circuits shut
off.
“How to Program a Release End
Bell Circuit” on page 105
REL CKT ULC Directs outputs to perform a release
function as required by ULC.
“How to Program a ULC Release
Circuit” on page 106
RELEASE CKT Directs outputs to perform a
releasing function.
“How to Program a Release Circuit”
on page 107
REL. FORM C Directs relay outputs to perform a
releasing function.
“How to Program a Release Form-
C Circuit” on page 108
REL AUDIBLE Activates audio or visual devices
steady when releasing starts.
“How to Program a Release Audible
Circuit” on page 109
INST RELEASE Activates non-releasing output (SLC
modules) with no delay time.
“How to Program an Instant
Release Circuit” on page 110
