Figure 35: MBC connections for cable 120
LD27277b
092-51870-015
REV B, SHT. 1,2 & 3
Cable 120:
VSD/MBC Fiber to
OptiView Panel
VSD/MBC
Fiber Comms End
OV Panel End
Blue & Gray
Connectors
Note: See Figure 3 for TB15 details, Figure 30 for P7 details, and Figure 11 for TB7 details.
61Unit Wiring and Field Connections for YZ Centrifugal Chiller with Magnetic Bearing Controller
