OptiView hot gas bypass connections for cables 22 and 23
Figure 48: OptiView hot gas bypass connections for cables 22 and 23
LD23074
(Optional)
Hot Gas Bypass
Detail G
092-62925-000
REV B, SHT.7
OVA
See Detail H
Hot Gas Bypass
See Detail G
Detail H
Cable 22
Cable 23
Orifice Variable Actuator
