Johnson Controls YZ - OptiView refrigerant and discharge pressure cable connections

OptiView refrigerant and discharge pressure cable
connections
Figure 45: OptiView refrigerant and discharge pressure cable connections
LD27291
092-62925-000
REV B, SHT.5
Detail C
See Detail B
See Detail C
Detail B
Cable 6 Drop Leg
Refrigerant Temp.
Cable 48 Condenser
Refrigerant Temp.
Cable 15 Refrigerant
Level to Optiview™
Cable 24
Discharge Pressure
71Unit Wiring and Field Connections for YZ Centrifugal Chiller with Magnetic Bearing Controller
