VSD shielded cable entry view from outside of OptiView
panel
Figure 50: VSD shielded cable entry view from outside of OptiView panel
092-62925-000
REV B SHT.2
Shielded Cable Entry View
From Outside of The Panel
Cable 52
(OptiView Fault to VSD)
Unit Wiring and Field Connections for YZ Centrifugal Chiller with Magnetic Bearing Controller76
