MBC connections
Note: See Figure 13 and Figure 17 for purge unit wiring and OptiView control center
connections.
MBC cable connections from outside of the OptiView panel
Figure 28: MBC cable connections from outside of the OptiView panel
LD27273
092-62925-000
REV B, SHT. 2
Cable 19 (MBC)
Unit Wiring and Field Connections for YZ Centrifugal Chiller with Magnetic Bearing Controller50
