Johnson Controls YZ - OptiView connections for 1020 A and 1280 V VSD connector plates

OptiView connections for 1020 A and 1280 V VSD connector
plates
Figure 44: OptiView connections for 1020 A and 1280 V VSD connector plates
LD27290
092-62925-000
REV B, SHT.3
Detail A
1020A and 1280A VSD Connector Plate
will be Horizontal instead of Vertical
330A, 420A and 780A
VSD Connector Plate
See Detail A
OVC
MWT
MBC
(LV)
UPS
OV
FAUL
OVP
PURGE
MBC
(HV)
VGD
FOC
Cable 52
VSD to Optiview Fault
Note: See VSD connections for Cable 52 details.
Unit Wiring and Field Connections for YZ Centrifugal Chiller with Magnetic Bearing Controller70
