JRC JMA-610 Series User Manual

1-3
1
1.3 CONFIGURATION
y
1.3 CONFIGURATION
Scanner and Transmitted Output Power
SCANNER TYPE
TRANSMITTED
OUTPUT POWER
BAND
JMA-610 7 FT SLOT ANTENNA
4.9 kW
X
Radar Configuration and Ship’s Mains
RADAR
MODEL
SCANNER
UNIT
CONTROL UNIT SHIP’S MAINS
JMA-610 NKE-316 NCM-883 24 VDC
Notes:
1. An optional rectifier is necessary for using Ship's Mains 100/110/115/200/220/230 VAC.
2. The control unit NCM-883 has a separate structure consisting of the following
:
Radar process unit NDC-1486
Operation unit NCE-7882A

JRC JMA-610 Series Specifications

General

Brand	JRC
Model	JMA-610 Series
Category	Radar
Language	English
