JRC JMA-610 Series User Manual

2-2
2
2.1 NAMES AND FUNCTIONS OF CONTROL PANEL SWITCHES
yy
2.1 NAMES AND FUNCTIONS OF CONTROL
PANEL SWITCHES
Names and Functions of Control Panel Switches
Simple explanation is described from next page.
Fig 2.2 CONTROL PANEL
1 ψSTBY (Standby) key
2 ψTX (Transmit) key
3 ψEBL1/2 (Electric Bearing Line 1/2) key
4 ψALARM ACK
(Alarm Acknowledgement) key
5 ψOFF CENT (Off Center) key
6 ψGAIN dial
7 ψP-LINE (Parallel Index Line
Line
)
Ke
y
9 ψRAIN (Rain/Snow clutter Suppression) dial
10 ψDAY/NIGHT (Day/ Night Mode) key
11 ψSEA (Sea Clutter Suppression) dial
12 ψHL-OFF (Heading Line Off) key
13 ψTUNE/AUTO (Tune Control/
Automatic) dial
14 ψENTER key
16 ψVRM1/2 (Variable
Range Marker 1/2) key
17 ψJog dial
18 ψPhotoshot ٤
R
(Screen Capture) key
19 ψEXP (Echo Expansion)
key
20 ψAIS LABEL (Vessel
name) key
21 ψOWN VECT (Vector
Length) key
8 ψBRILL (LCD
Brilliance) key
15 ψMENU key
22 ψTrack ball
23 ψ+RANGE- (Range
Scale) key
24 ψRANGE RINGS
(Fixed Range Marker) key
25 ψPANEL (Operation Panel
Brilliance) key
