3-18
3.5.3 Use VRMs (Variable Range Markers) [VRM1/VRM2]
This function is to display and select variable range markers (VRMs). Two VRMs are available: VRM1 is
represented as a broken line, and VRM2 as a dotted line.
VRM1 Operation
If VRM2 is selected or VRM1 is not displayed, press [VRM1/VRM2] key to select VRM1 before
starting operation.
(The currently selected VRM is highlighted at the lower right of the screen.)
Procedures 1 Press [VRM1/VRM2] key to select VRM1.
VRM1 at the lower right of the screen will be highlighted, and VRM1 becomes operable.
2 Adjust the range of VRM1 with [JOG DIAL] or [TRACKBALL].
3 Press [ENTER] key .
The range of VRM1 is fixed .
VRM2 Operation
If VRM1 is selected or VRM2 is not displayed, press [VRM1/VRM2] key to select VRM2 before
starting operation.
(The currently selected VRM is highlighted at the lower right of the screen.)
Procedures 1 Press [VRM1/VRM2] key to select VRM2.
VRM2 at the lower right of the screen will be highlighted, and VRM2 becomes operable.
2 Adjust the range of VRM2 with [JOG DIAL] or [TRACKBALL].
3 Press [ENTER] key .
The range of VRM2 is fixed.
CLEARING VRM
Procedures 1 Hold down [VRM1/VRM2] key.
The VRM (current selected VRM) display will disappear.
Or put the cursor on VRM1 / VRML2 and hold down [ENTER] key.
