3-50
3.8 USER SETTING
The operation status of the radar is recorded. If the system is operated by more than one operator, the
operators can register operation status as suitable for them and call the status. Operation status for up
to five operations can be registered, and a name be assigned to each status. (Up to 10 alphanumeric
characters)
The status is saved in an internal memory, therefore a flash memory card is not necessary for this
function.
<Data saved by the “User Setting”>
x Display Color and Brilliance Setting menu
x Buzzer Volu
me
x EBL / VRM Control CURS
3.8.1 USER SETTING (Load User Setting)
The operating state saved in the system can be loaded by performing the operation below.
When the operating state is loaded, the previous operating state is discarded. Therefore, if you
do not want to discard the operating state data, save the operating state by performing the
operation described in Section 3.8.2.
Procedures 1 Press [MENU] key.
Select 8.Next and press [ENTER] key.
Select 2.User Setting and press [ENTER] key.
2 Select 1.Load User Setting and press [ENTER] key.
3 Select “user setting file” and press [ENTER] key.
Confirmation Window will appear.
4 Select 1.Yes and press [ENTER] key.
The operating state data will be loaded.
3.8.2 USER SETTING (Save User Setting)
The system’s current operating state can be saved in the system by performing the operation
below.
Procedures 1 Press [MENU] key.
Select 8.Next and press [ENTER] key.
Select 2.User Setting and press [ENTER] key.
2 Select 2.Save User Setting and press [ENTER] key.
Select file number and press [ENTER] key.
Input the “file name”, select Enter and press [ENTER] key.
Confirmation Window will appear.
3 Select 1.Yes and press [ENTER] key.
The operating state data will be saved.
To Next Page
