5-35
3) Specifie data source (Source) about the each item.
The data sourse setting of the heading
The data sourse setting of the Log
・GYRO I/F： Select when using Synchro/Step Gyro for the data source.
・GYRO(NMEA)： Select when using NMEA Gyro for the data source.
・GPS Compass：Select when using GPS Compass for the data source.
G
ro
・Select when wanting to make an optional value heading and enter a value.
Manual
・GYRO I/F： Slect when using puls log for the data source.
・NMEA LOG： Slect when using NMEA output log for the data source.
Lo
・Select when wanting to make an optional value speed and enter a value.
Manual
Specifie data source (Source).
(GYRO I/F , GYRO (NMEA) or GPS Compass)
［Use Local Port］：Recive a sensor data route terminal board.
［Use LAN］： Recive a sensor data route LAN.
・When Selecting GYRO I/F in Source, input an default value.
After value input, left-click the [Set] button and fix the value.
GYRO Setting
Specifie data source (Source).
（GYRO I/F or NMEA LOG）
［Use Local Port］：Recive a sensor data route terminal board.
［Use LAN］： Recive a sensor data route LAN.
To Next Page
