JRC JMA-933B User Manual

1-1
1. Configuration
1.1 Components
A list of components and optional accessories are shown below.
1.1.1 JMA-900B Series
●JMA-900B Series List of Composition (Self Satanding TYPE)
MODEL
Scanner
Unit
Radiator
Performance
Montor
Tranceiver
Unit
Display Unit
JMA-933B-SA NKE-1139 NTG-3230
JMA-932B-SA NKE-1130
NJU-84
---
JMA-923B-7XA NKE-1129-7 NAX-16B-7
JMA-923B-9XA NKE-1129-9 NAX-16B-9
NTG-3225
JMA-922B-6XA NKE-1125-6 NAX-16B-6 ---
JMA-922B-9XA NKE-1125-9 NAX-16B-9
NJU-85
---
NCD-2096
●JMA-900B Series List of Composition (Desktop TYPE)
Display Unit NCD-2096F
MODEL
Scanner
Unit
Radiator
Perfor
mance
Monitor
Tranciver
Unit
Monitor
Unit
Process
Unit
Operation
Unit
JMA-933B-SA NKE-1139 NTG-3230
JMA-932B-SA NKE-1130
NJU-84
---
JMA-923B-7XA NKE-1129-7 NAX-16B-7
JMA-923B-9XA NKE-1129-9 NAX-16B-9
NTG-3225
JMA-922B-6XA NKE-1125-6 NAX-16B-6 ---
JMA-922B-9XA NKE-1125-9 NAX-16B-9
NJU-85
---
NWZ-170-ET NDC-1444 NCE-5163-FT
*1 Input voltage is selectable. “1” or “2” suffix is attached to model name of scanner unit. “1” means
AC100-115V (50/60Hz) and “2” means AC220-240V (50/60Hz) for type of scanner unit NKE-1139,
NKE-1130, NKE-1129-7, NKE-1129-9, NKE-1125-6, NKE-1125-9.
*2 HETER OPTION is available at suffix “D”.
Ex）NKE-1139-1 D 、NKE-1129-92 D
1: AC 100-115V 50/60Hz 1φ
2: AC 220-240V 50/60Hz 1φ
D: HETER OPTION
