JRC JMA-933B User Manual

2-19
2.1.2 H-2695111153*
This is an 18-core shielded composite cable.
This cable is used to connect an interswitch to the display unit.
Fig 2-2 Cross-sectional drawing H-2695111153*
Table 2-2 H-2695111153* wire
Wire NO.
Cross Section (m
2
)
No. of wire / φ Color Remarks
A1
0.5
19 / 0.18 Black 1 Coaxial
A2
0.5
19 / 0.18 Black 2 Coaxial
B1
0.5
19 / 0.18 Blue Shield
B2
0.5
19 / 0.18 Yellow Shield
B3
0.5
19 / 0.18 Green Shield
B4
0.5
19 / 0.18 Red Shield
B5
0.5
19 / 0.18 Purple Shield
B6
0.5
19 / 0.18 Clear Shield
0.3
Blue
0.3
White
0.3
Yellow
0.3
White
D1
0.5
19 / 0.18 Brown
D2
0.5
19 / 0.18 Black
D3
0.5
19 / 0.18 Orange
D4
0.5
19 / 0.18 Gray
D5
0.5
19 / 0.18 Pink
D6
0.5
19 / 0.18 SkyBlue
C1 12 / 0.18 2 Cores Shield
C2 12 / 0.18 2 Cores Shield
Maximum diameter 18.0mm
“*” means revision, such as A, B and so on.
