1-14
1.4 System Configuration
NCD-2096 component units
Item Unit Type Qua
ntity
Remarks
23.1 Inch LDC Unit H-7WSRD0002* 1
Monitor Unit
Interconnection
CML-764-E/ET 1
Monitor Unit
NWZ-170-E/ET
LCD OPE CCK-972 1
Operation Circuit A CCK-973 1
Operation Circuit B CCK-974 1
Operation Circuit C CCK-975 1
Operation Circuit D CCK-976 1
Operation Unit
NEC-5163-F/FT
Operation Unit
Interconnection
CMD-996-F/FT 1 Incluce in Trackball
μATX Mother Board CMC-1323 1 Made from PFU
CPU Include in CMC-1323 1 Intel Pentium M1.6G
Main Memory Incluce in CMC-1323 1 512MB
ADD Card CKA-141 1
Silcon Disk Drive CDD-723 1 More than 2GB
HDD CDD-717 2 Serial ATA 80GB
USB FD Drive CDD-719 1
DVD Drive CDD-722 1
Front Panel Circuit 1 CCK-986 1
Front Panel Circuit 2 CCK-987 1
ATX Power Supply CBD-1625 1 Include in UPS Function
Contorol
Unit
USB Secrity Dongle CYC-344 1
Main Power Supply CBD-1832 1 Include in filter circuit Power
Supply
UPS Battery CBD-1831 1
RADAR Interface
Board
CDC-1338 1
RADAR Processor
Board
CDC-1339 1
Radar
Unit
ARPA Unit CDC-1186D 1
SRB1 CDJ-2373 1
GYRO I/F CMJ-462E 1 Option
Backplane
Motherboard
CQC-1219 1
Outside
I/F Unit
Outside I/F Unit
Interconnection
CFQ-5438 1
Standard Terminal
Board
CQD-2121 1
Radar Terminal
Board
CQD-2128 1
Display Unit
NDC-1445/1444
Terminal
Board
Unit
Option Terminal
Board
CQD-2130 1 Option
“*” means revision, such as A, B and so on.
To Next Page
