5-16
Setting of the ”Sensor”
“Sensor” of the [Sensor Set] dialog select Use/Not Use of the sensor. When selecting Use, the sensor
data which connected with the termainal board can be used. Set to Not Use therefore at the sensor not to
use.
(1) Select the sensor to set from
the ”Sensor Name”
(2) Set the type of the sensor
(3) Set Use/Not Use of the sensor
Set the recepthion course of SRB
（Standard/Optional）
Set the port of SRB
Set ON/OFF of the checksum
Set the time-out of the sensor
To Next Page
