FX-1/FX-1R Maintenance Manual
1-2. Replacing the Pulleys
1-2-1. Replacing the Pulley YA
(1) Carry out the replacement work in the same manner as for the timing belt YM in 1-1-1.
1-2-2. Replacing the Pulley YM
(1) Carry out the replacement work in the same manner as for the timing belt YM in 1-1-1.
1-2-3. Replacing the Pulley YB
(1) Carry out the replacement work in the same manner as for the timing belt YB in 1-1-2.
1-3. Replacing the Servomotors
(1) Carry out the replacement work in the same manner as for the timing belt YM in 1-1-1.
1-5
Rev. 2.00
