JUKI FX-1R - Replacing the Head up Spring; MNLA Head

FX-1/FX-1R Maintenance Manual
2-5. Replacing the Head Up Spring
2-5-1. MNLA Head
Replacing the head up SP
(1) Follow step (1) described in section 2-1 to detach the head top cover.
(2) Replace the head up SP.
Figure 2-5-1
Head up SP
L151E221000
2-9
Rev. 2.00
