4-6. Adjusting the OCC Light Quantity
<Procedure>
 Check that the OCC light goes on with manual control.
 Carry out "Adjustment of OCC Light" in the MS parameters. (See the section related to OCC
light quantity adjustment in the specifications for the MS parameter operation.)
4-7. List of Readjustment Items After Replacement
Table 4-7-1 List of Readjustment Items after Replacement
Camera
assembly
Light assembly
CCD camera
lens
Light board
assembly
Light filter
Focus adjustment
○ ― ○ ― ―
Filter adjustment
△ ○ △ ― ○
Light adjustment
△ ○ △ ○ ○
Origin coarse adjustment
(Note)
○ ― ○ ― ―
OCC offset (Note)
○ ― ○ ― ―
Head offset (Note)
○ ― ○ ― ―
BMR offset (Note)
○ ― ○ ― ―
HMS offset (Note)
○ ― ○ ― ―
○: Mandatory
△: Check
−: Unnecessary
(Note) See the specifications for the MS parameter operation.
 CAUTION
To prevent personal injury, do not put your hand inside the machine
or your face or head close to the machine during operation of the
HOD.
