FX-1/FX-1R Maintenance Manual
14-4. Running the cables and setting up the driver
The following shows how to run the cables and set up the driver.
{ Front reference
Sensor cable
Position relay board
Motor cable
To the to
of the trans
ort unit.
xis setting rotary
switch “4”
To the inside of the chassis (to
be passed through a position
between the conveyor mount
plate S and chassis).
Position relay board
• Connect the sensor cables to CN25.
• Set the jumper
setting of W5
as shown in the
figure on the right.
×
3
1
AWCS
W5
{
IN/OUT AWC drive
Figure 14-4-1
14-4
Rev. 2.00
