FX-1/FX-1R Maintenance Manual
15-2. Structure of components inside FPI
Wire fixing part
Timer spacer A
Wire
fixing part
Plastic slider
M3
×
3, Binding
machine screw
FPI insulation sheet
M4 x 6, Flat head screw
Connector of FPI LED CABLE ASM
Figure 15-2
15-2
Rev. 2.00
