10 Configuration level 1
46
r Inputs
v Page 52
r analogue input 1—4
supply frequency
unit
r transducer
linearisation
measurement correction
constant cold junction
temperature
external cold-junction
temperature
display start
display end
range start
range end
filter time constant
customized
recalibration r start value
end value
r Outputs
v Page 57
r output 1—6 r function
output signal
zero point
end value
output signal on
over/underrange
r Profile controller
v Page 59
r function
restart
program start
setpoint input
time/gradient
programming
function control
programming
process value deviation
program end time
r controller
limit comparator 1—8
r Maths/logic
v Page 62
r mathematics 1+2
Logic 1+2
r function
variable a
variable b
range start
range end
linearisation
r Display
v Page 67
r configuration 1+2
time-out
automatic
display switching
r display 1—3 r display value
decimal point
r Logic function
v Page 70
r logic input 1—8
limit comparator 1—8
logic output 1+2
operating contact 1—8
tolerance band signal
program end signal
r Interface
v Page 73
r protocol type
data format
unit address
minimum response time
r baud rate
parity
stop bit
➔ = press E !
