73
10 Configuration level 1
10.9 Interface
CONFIG 1 ➔ INTERFCE
Parameter Value/selection Description
Protocol type ➔ PROTOCOL MODBUS
MODINT
MODbus/Jbus
MODbus int
Data format
Baud rate
Parity
Stop bit
➔ DATAFMT
➔ BAUDRATE
➔ PARITY
➔ STOP BIT
1200
2400
4800
9600
19200
NONE
ODD
EVEN
ZERO
1
2
1200 bps
2400 bps
4800 bps
9600 bps
19200 bps
no parity
odd parity
even parity
zero parity
1 stop bit
2 stop bits
Unit address ➔ UNITADDR 0. 0—1 —254
Minimum
response time
➔ MIN TIME 0. 0—500msec
Minimum period of time which
elapses between the request of an
instrument within a data network
and the response of the controller
Factory settings are shown bold.
Interface description B 703570.2
Interface description B 703560.2.3
