10 Configuration level 1
General The following applies to the representation of parameters and functions on the
unit:
The parameter is not displayed when
-the instrument features do not permit the function assigned to
the parameter.
Example: Output 3 cannot be configured if output 3 is not available
to the instrument.
-the parameter is irrelevant to the function that was previously configured.
Example: Analogue input 1 is configured to “Pt100”, which means that
display start/end for standard signals will not be displayed.
Access level
by ...
h pressing
P 5 times in the basic status or in the manual operating mode
Access code The level is protected by a code.
factory-set code: 0002
Overview
r Controller
v Page 47
r controller type
control direction
controller inputs
setpoint limits
manual output
manual operating mode
self-optimisation
output 1+ 2 for
self-optimisation
dead band
fuzzy control 1
fuzzy control 2
r
r
process value
external setpoint
external setpoint
with correction
stroke retransmission
additive disturbance
multiplying disturbance
setpoint start
setpoint end
r Limit comparators
v Page 49
r limit comparator 1—8 r function
action
switching differential
limit value
function on over/
underrange
switch-on delay
pulse function
LK inputs
r
limit comparator PV
limit comparator setpoint
➔ = press E !
