JUMO DICON 401 User Manual

9
2 Identifying the instrument version
2.1 Type designation
* Type 703580 only
Delivery package
-Profile controller/generator
-2 mounting brackets
-seal
-Operating Manual B 703580
(1) (2) (3) (4) (5) (6) (7)
703580/ 0 – – – – / ,
Format 96 mm x 96 mm
703585/ – 0 0 – 0 0 0 – – / ,
Format 48 mm x 96 mm and 96 mm x 48 mm
(1) Basic type extension
Format:
96mm x 96mm 0
48mm x 96mm portrait 1
96mm x 48mm landscape 2
Version:
Standard with factory default
settings 8
Customized programming 9
Language for instrument texts:
German 1
English 2
French 3
(2) Analogue input 1 2 3 4
not assigned 0 0 0 0
Universal input
(all transducers except
voltage -10/2/0 — 10V)
1111
voltage -10/2/ 0 — 10V 2 2 2 2
(3) Output 1 2 3 4 5 6
not assigned 0 0 0 0 0 0
Relay (changeover
contact) 1 1 1 1 1 1
Solid-state relay
230V 1A 2 2 2 2 2 2
Logic 0/5V 3 3 3 3 3 3
Logic 0/22V 4 4 4 4 4 4
Analogue output 5 5 5 5 5 5
Supply
for 2-wire transmitter 6 6 6 6 6 6
Two logic inputs 7 7 7 - - -
(4) Supply
110 — 240V AC +10/-15%
48 — 63Hz
20 — 30V AC/DC 48 — 63Hz
2
2
3
5
(5) Interface
not assigned 0 0
RS422/485 5 4
PROFIBUS-DP
(no GL approval)
64
(6) Maths and logic module
not available 0 0
available 0 3
(7) Approvals
DIN EN 14597
*
056
Germanischer Lloyd (GL)
*
062
DIN EN 14597 and GL
*
063
DIN EN 14597 and UL
*
064
GL and UL
*
065
DIN EN 14597, GL and UL
*
066
