10 Configuration level 1
Constants
Enabling the
maths and
logic module
The maths and logic module can be enabled through a code via the setup pro-
gram.
v Extras r Enabling extra codes
10.7 Display
The two display configurations are set here, as well as the time-out during
configuration at the levels
PEND
program end
TOL
tolerance band signal
Constant name
Note
TRUE
logic 1
FALSE
logic 0
Variable name
Note
CONFIG 1 ➔ DISPLAY
Parameter Value/selection Description
Configuration 1 ➔ DSPCONF1 Configuration of the displays as in
the example “Configuration 1”
below.
Configuration 2 ➔ DSPCONF2
Time-out ➔ TIMEOUT 30. 0—30 —9999sec
0 = time-out OFF
Interval after which an automatic
return to basic status occurs if no
key is pressed.
Automatic
display switching
➔ SCROLL 0. -1 — 0 — 9999sec
0 = automatic changeover OFF
-1 = no switching from keys
Interval between switching from one
display configuration to the other
Language for
instrument texts
➔ LANGUAGE DEUTSCH
ENGLISH
FRANCAIS
ESPANOL
German
English
French
Spanish
This feature is available from inst-
rument SW version 050.03.01.
Factory settings are shown bold.
