10.8 Logic functions
Functions are assigned here to the logic signals of the logic inputs, limit com-
parators, operating contacts, tolerance band signal, profile program end signal
and of the logic module.
CONFIG 1 ➔ LOGICFCT
Parameter Value/selection Description
Logic input 1 ➔ LOGIN B1 NO FUNCT
TUNESTRT
TUNESTOP
W SWITCH
X SWITCH
P SWITCH
KEYINHBT
LEVINHBT
TXTDISPL
DISPLOFF
AUTOHAND
PGMINHBT
PGMSTART
PGMSTOP
PGMABORT
PGMSELCT
FFWD
NEXTSEG
no function
start of self-optimisation
cancel self-optimisation
setpoint switching
process value switching
parameter set switching
key inhibit
level inhibit
text display*
all displays off/acknowledge LK
auto/manual changeover
programming inhibit
profile program start
profile program stop
profile program abort
profile program selection
fast forward**
change of segment
* A maximum of 10 texts is input and
assigned to the logic functions in the
setup program.
** The speed of the program run is
increased dynamically
The functions are active when the
contact is closed or the switching
status is “ON”.
Profile program start:
The program is started immediately.
The start day/start time and delay
settings (“program start” level) are
ineffective.
All displays off:
- all displays are off
- limit comparators are acknowl-
edged
Text display and all displays off:
response according to priority list
... ...
Logic input 8 ➔ LOGIN B8
Limit comparator 1 ➔ OUT LK1
... ...
Limit comparator 8 ➔ OUT LK8
Logic 1 ➔ LOGIC 1
Logic 2 ➔ LOGIC 2
Operating contact 1 ➔ OPCNTCT1
... ...
Operating contact 8 ➔ OPCNTCT8
Tolerance band
signal
➔ TOLBAND
Profile program
end signal
➔ PGM END
Factory settings are shown bold.
