53
10 Configuration level 1
Linearisation ➔ LINTAB LINEAR
PT100
PT1000
PT500
PT50
CU50
KTY
PTK9
NI100
TC TPE J
TC TPE E
TC TPE K
TC TPE N
TC TPE T
TC TPE B
TC TPE R
TC TPE S
TC TPE U
TC TPE L
CUST LIN
W5RE W26
W3RE W25
W3RE W26
linear
Pt 100
Pt 1000
Pt 500
Pt 50
Cu 50
KTY21-6 (1kΩ at 25°C)*
Pt K9
Ni 100
Fe-Con J
NiCr-Con E
NiCr-Ni K
NiCrSi-NiSi N
Cu-Con T
Pt30Rh-Pt6Rh B
Pt13Rh-Pt R
Pt10Rh-Pt S
Cu-Con U
Fe-Con L
customized linearisation**
W5Re-W26Re
W3Re-W25Re
W3Re-W26Re
* for other types, see setup
program (extended configuration)
** for customized linearisation, up to
20 interpolation points can be
realised (with setup program only).
x = physical measured value
y = display value
Measurement
correction
➔ OFFSET 0. -1999—0 to +9999 digit
Measurement correction can be
used to correct a measured value by
a certain amount upwards or down-
wards.
Examples:
measured displayed
value offset value
294.7 +0.3 295.0
295.3 - 0.3 295.0
The controller uses the
A corrected value (= displayed
value) for its calculation.
This value does not corres-
pond to the actually measured
value.
If incorrectly applied, this can
result in impermissible values
of the control variable.
CONFIG 1 ➔ INPUTS ➔ ANALOG 1
Parameter Value/selection Description
Factory settings are shown bold.
