10 Configuration level 1
Functions
ADRB
storage address (binary)
LK1
…
LK8
output limit comparator 1
…
output limit comparator 8
SK1 — SK8
operating contact 1 — operating contact 8
B1
…
B8
logic input 1
…
logic input 8
L1
L2
logic 1
logic 2
PEND
program end
TOL
tolerance band signal
Syntax Function
SQRT(a)
square root of a
Examples: SQRT(E2)
SQRT(13.5+E3)
MIN (a1, a2 …)
returns the smallest value of a series of arguments
Examples: MIN(3, 7) (returns the value 3)
MIN(E1, E2, E3, 0.1)
MAX (a1, a2 …)
returns the largest value of a series of arguments
Examples: MAX(3, 7) (returns the value 7)
MAX(E1, E2, E3, E3, 0.1)
LOG(a)
logarithm to base 10
Examples: LOG(1000) (returns the value 3)
LOG(E1/100)
LN(a)
logarithm to base e
Examples: LN(2.71828128) (returns the value 1)
LN(E1/100)
SIN(a)
sine of a
a in degrees (0 — 360°C)
Examples: SIN(90) (returns the value 1)
SIN(E1*360/100)
COS(a)
cosine of a
a in degrees (0 — 360°C)
Examples: COS(180) (returns the value -1)
COS (E1*360/100)
TAN(a)
tangent of a
a in degrees (0 — 360°C)
Examples: TAN(45) (returns the value 1)
TAN(E1*45/100)
